Компактный портативный стоматологический рентген
Ультракомпактный рентген для быстрой съёмки.
MX-70 dental X-ray system — compact portable unit for dental, veterinary, and clinical imaging applications.
Технические характеристики
| Device Classification | Class II |
|---|---|
| DC High Frequency | 300 kHz |
| Power Rating | 500 W |
| Maximum Power | 750 VA |
| Nominal Voltage (Accuracy) | 60 / 65 / 70 kV |
| Nominal Current (Accuracy) | 4 to 7 mA |
| Focal Spot Size (IEC 60336) | 0.4 mm |
| Anode Angle | 12.5° |
| Inherent Filtration | 1.0 mm Al |
| Total Filtration | Min. 2.0 mm Al |
| Source to Skin Distance | 200 mm (8 in.) |
| X-ray Field Collimation | Φ60 mm / 30 × 40 mm² |
| Power Supply Voltage | AC 230V ±10%, 50/60 Hz |
| Cooling System | Oil cooling |
| Duty Cycle | 1:60 or greater |
| Radiation Leakage | ≤ 0.25 mGy/h |
| Operation Conditions | Temperature: 59–86°F (15–30°C) — Humidity: 15–95% RH |
Resun reserves the right to modify the design and specifications contained herein without prior notice.
Доступность и спецификации могут отличаться по регионам.
