Dental Imaging Plate Scanner (PSP)
Phosphor storage plate digitizer for dental, veterinary, and clinical imaging workflows.
New standard for digital X-rays. Easy and reliable.
High-resolution imaging by applying MPPC (Multi-Pixel Photon Counter) with high photon detection efficiency.
Suitable for dental, veterinary, and general clinical PSP digitization workflows.
Key Features
- Resolution (theoretical): 20 lp/mm
- Supported PSP sizes: 0, 1, 2
- Readout time: less than 10 seconds
- 16-bit image gray levels (65,536 gray levels)
- DICOM 3.0, TIFF, BMP, JPEG export
Technical Specifications
| Supported PSP Size | 0, 1, 2 |
|---|---|
| Readout Time | Less than 10 seconds |
| Image Gray Levels | 16 bit (65,536 gray levels) |
| Computer Interface | 10/100Mbps Ethernet |
| Dimensions | 130 (W) × 245 (D) × 168 (H) mm — 5.12" × 9.65" × 6.61" |
| Weight | 3 kg / 6.6 lbs |
| Power Supply | Input: 100–240V, 50/60Hz — Output: DC24V, 2.5A |
| Image File Format | DICOM 3.0, TIFF, BMP, JPEG |
| Operation Conditions | Temperature: 59–86°F (15–30°C), gradient 0.5°C/min — Humidity: 15–95% RH |
| Image Pixel Size (Premium / Standard) | 25 μm / 50 μm |
Resun reserves the right to modify the design and specifications contained herein without prior notice.
Product availability and specifications may vary by region. Contact us for detailed datasheets and export support.
